Flat Printer
LT-2513P Technical Specifications
| Model | LT-2513P |
|---|---|
| Printhead Type | I3200 (2-8H) / Konica 1024i (4-16H) |
| Printing Speed | 19–76㎡/h (I3200) / 33–180㎡/h (1024i) |
| Print Width | 2.5 m × 1.3 m |
| Package Size | 4360 mm (L) × 2120 mm (W) × 1610 mm (H) |
| Net / Gross Weight | Net: 1550 kg / Gross: 1670 kg |
| Media Type | KT board, PVC board, acrylic, wood board, metal plate, glass, cardboard, etc. |
| Computer Configuration | WIN7+ 64-bit; CPU i5+; 8 GB RAM; ASUS motherboard 3.0 GHz; SSD 150 GB; includes 1 TB HDD; LAN Network |
| Platform Functions | Zoning control of double adsorption fans |
| Temperature & Humidity | Temperature: 20–30 °C; Humidity: 50–60% RH |
| Software | Maintop / Photoprint (Optional) |
| Power | 7000 W (including 3000 W suction fan) |
